3.3 Storage
ATTENTION
Damage to the GTES due to incorrect storage
Incorrect storage can lead to damage to the components of the GTES. Only store the GTES under
the following conditions:
► Do not store outdoors.
► Store in a dry and dust-free place.
► Do not expose to aggressive media.
► Avoid mechanical vibrations.
► Storage temperature: same as the ambient temperature during operation, avoid rapid temperature
fluctuations.
► Maximum relative humidity, 60 %.
For storage periods longer than 12 months, the general condition of all parts and the packing must be checked
regularly. Stromag’s Customer Care can provide you with information on this, please refer to section 11.2 for the
address.
NOTE
Details for storage on the packing pieces that go beyond the requirements specified here, must be
observed.
4 Technical specifications
4.1 Product data
4.1.1 Dimensions
For assembly of the housing cover, a clearance space in transverse direction of the height of the housing cover
must be provided.
For the cable entry point, the minimum bending radius of the customer connecting cable must be observed.
4.1.2 Mechanical specifications
NOTE
The shift in revolutions is considered with the viewing direction to the shaft.
If necessary, the maximum input speed can be higher for short time operation. Consulting with Stro-
mag is required.
10
Mounting/operating instructions Gear limit switch Type series HGE • No. 152-00000 F • 10/2017
