Gearbox - Table 1 for contacts 80, 81, 88, 90, 90G with cam discs 40° FV70
Nominal revolutions
usable revolutions
with 40° cam disc
Castor revolutions of the
drive shaft after each side
Mechanical Hysteresis
Max. input speed [min-1]
Min. input speed
for alternating operation
[rpm]
Min. drive torque for
switching a single contact
[Nm]
Max. drive torque
for forced opening
of a single contact [Nm]
Contact
80, 90,
90G
Contact 88 Contact
80/81
Contact
90, 90G
Contact 88
9,5 10,67 1,333 0,073 0,097 250 3,638 1,819 0,364 0,20 0,371
18 18,29 2,286 0,125 0,166 250 6,236 3,118 0,624 0,20 0,300
22 22,40 2,800 0,154 0,203 250 7,639 3,820 0,764 0,20 0,281
29 29,64 3,705 0,203 0,269 250 10,108 5,054 1,011 0,20 0,261
35 44,44 5,556 0,305 0,403 500 15,158 7,579 1,516 0,10 0,141
70 76,19 9,524 0,523 0,691 500 25,984 12,992 2,598 0,10 0,124
85 93,33 11,667 0,640 0,846 500 31,831 15,915 3,183 0,10 0,120
100 107,25 13,406 0,736 0,972 500 36,576 18,288 3,658 0,10 0,117
115 123,50 15,437 0,847 1,120 750 42,118 21,059 4,212 0,10 0,115
155 155,56 19,444 1,067 1,410 750 53,052 26,526 5,305 0,10 0,112
180 194,18 24,272 1,332 1,760 750 66,223 33,112 6,622 0,10 0,109
230 230,30 28,788 1,580 2,088 1000 78,544 39,272 7,854 0,05 0,058
260 264,08 33,010 1,811 2,394 1000 90,064 45,032 9,006 0,05 0,057
305 313,21 39,152 2,148 2,839 1000 106,820 53,410 10,682 0,05 0,056
345 352,36 44,045 2,417 3,194 1000 120,172 60,086 12,017 0,05 0,055
460 476,00 59,500 3,265 4,315 1000 162,338 81,169 16,234 0,05 0,054
715 740,44 92,556 5,079 6,712 1000 252,526 126,263 25,253 0,05 0,052
11
Mounting/operating instructions Gear limit switch Type series HGE • No. 152-00000 F • 10/2017
