5 Construction and function

5.1 Switch sizes

EKM-0127

A1R A1L

B11

Fig. 4

A1R

Switch size A1R

B11 Switch size A1R

A1L

Switch size A1L

The switch sizes shown in the figure above present a selection. The overview of all switch sizes can be obtained

from the type code explanation, see section 4.1.6.

Mounting/operating instructions Gear limit switch Type series HGE • No. 152-00000 F • 10/2017
