PART 1 • English
2.0 YOUR RECEIVER
2.1 DEFAULT PIN: 1234
2.2 Front Panel
Fig. 1
1. USB Connector for USB storage devices.
2. IR SENSOR Point your remote control towards this sensor.
3. MODE INDICATOR RED indicates that the receiver is in STANDBY mode.
GREEN indicates that the receiver is in OPERATING mode.
4. Standby/On button Switch the receiver ON to running mode or STANDBY mode
2.3 Rear Panel
Fig. 2
1. ANT IN To connect to your antenna for reception of broadcasted signals.
2. ANT OUT To connect the terrestrial antenna signal to your TV set.
This connection will allow you to watch digital terrestrial
programmes depending on the tuner of your TV and local
broadcast conditions.
3. S / PDIF COAXIAL To connect your receiver to a digital home theatre, AV receiver or
digital audio amplifier.
4. HDMI To connect your receiver with your TV set using an HDMI cable.
5. TV SCART To connect your receiver with your TV set using a SCART cable.
6. AUDIO R/L OUT To connect your receiver to an analogue audio amplifier.
7. POWER CORD Your receiver requires a supply voltage of 220~240 V AC
(Auto-selectable), 50/60 Hz ±5%. Please ensure the local power
specification meets these requirements before connecting your
receiver to the wall outlet.
2.4 Remote Control
Fig. 3
1. q Switches the receiver On/Standby
2. ! Mutes all audio outputs of the receiver
3. PG+/PG- Page up/down in all list modes
4. DTV/VCR No function
5. INFO Opens the current channel information; 2x opens the current
event information and 3x the signal information
6. VOL+/VOL- Increases/decreases the volume level
7. MENU Opens the main menu, in a menu you will get one step back
8. EXIT Exits from the menu or sub-menu
9. pq Menu Off: Change channel to previous/next.
Menu On: Moves the cursor up/down.
10. tu Menu Off: Increases/decreases the volume level.
Menu On: Change settings for specific menus
