Strong SRT 40FB4003 User Manual

Middle Detect and reduce moderate video noise.
High Detect and reduce enhanced video noise.
Default Set as Default.
5.3 Sound menu
Sound Mode Select your favourite sound mode for each input. Choices are Standard, Music,
Movie, Sports and User.
Bass Adjusts the lower frequency of the sound.
Treble Adjusts the higher frequency of the sound.
Balance Control the sound balance between the right and left loudspeaker
(earphone).
Auto Volume Adjust the volume corresponding to the input audio level. Options are On
and Off.
Surround Sound Turns on the Sound Retrieval System.
AD Switch Turn on the Audio description, you can activate the setting of AD volume.
When turn on the audio description, a narrator will describe what is
happening on the screen for blind or visually impaired viewers. (Only if
available in DTV mode.)
S/PDIF Mode If you have connected S/PDIF output to digital home audio system. You can
select “Auto” to output Dolby audio automatically. If channel have this audio
channel.
5.4 Channel
Press MENU to display the main menu. Press t u to select Channel in the main menu. Press pq to
select the option you wish to adjust in the Channel menu.
Press OK to adjust. After finish your adjustment, press OK to save and return to the previous menu.
Below items depend if they are available of select input source. Use INPUT to select another source.
5.4.1 Auto Tuning
Press pq to select Auto Tuning, select the Scan Type and proceed with OK.
5.4.2 Dish Setup
If you use DVB-S/S2 as input source, the Dish Setup menu allow you to set you satellite and belonging
settings as DiSEqC port and LNB type. Afterwards you may start the Auto Tuning or Manual Tuning by
selecting with EPG button the wanted transponder.
5.4.3 DTV Manual Tuning (in DVB-T mode only)
Search and store programmes manually. Press pq to select DTV Manual Tuning. Then press OK to enter
the sub-menu.
Press t u to select a Channel No., and then press OK to start the search. The search stops when a
programme is found and this programme will be stored in the current channel position. If you want to
stop the search, press MENU.
11
English

Strong SRT 40FB4003 Specifications

General

Screen shape	Flat
Response time	8.5 ms
Display diagonal	40 \
Display brightness	250 cd/m²
Display technology	LED
Native refresh rate	60 Hz
Contrast ratio (typical)	5000:1
Display diagonal (metric)	101 cm
Screen format adjustments	16:9
Motion interpolation technology	IQR (Image Quality Ratio) 100 Hz
3D	No
Battery type	AAA
Stand weight	100 g
Tuner type	Digital
Analog signal format system	Not supported
Digital signal format system	DVB-C, DVB-CI+, DVB-S2, DVB-T2
Operating system installed	-
RMS rated power	- W
Product color	Black
Panel mounting interface	200 x 200 mm
RF connector type	F, IEC
USB 2.0 ports quantity	1
S-Video inputs quantity	0
Power consumption (max)	74 W
Power consumption (standby)	0.5 W
Power consumption (typical)	54 W

Weight and Dimensions

Depth (with stand)	225 mm
Height (with stand)	526 mm
Weight (with stand)	3600 g
Depth (without stand)	63.9 mm
Width (without stand)	901 mm
Height (without stand)	511.3 mm
Weight (without stand)	3500 g
