Strong SRT 40FB4003 User Manual

broadcaster, it is possible to set it by pressing OK and set date and time by
pressing pq t u.
Time Zone Press p q t u to select Time Zone.
Sleep Timer Press p q to select Sleep Timer. Available Options: Off, 10 min., 20 min., 30
min., 60 min., 90min., 120 min.,180 min. and 240 min..
Auto Standby This function allows you to set the automatic shutdown of your TV. Choose
between 2H, 3H, 4H or Off to disable this function.
OSD Timer This function allows you to choose how long the info banner is displayed.
Choose between 5s, 15s or 30s.
5.6 Lock
Press MENU to display the main menu. Press t u to enter the Lock menu settings. Press p q to select
the options. The following options are available:
System Lock This option allows you to enable or disable the password protection. Press OK
to set this function On or Off.
Set Password The default password is 0000, to customize the password press OK and follow
the instruction within the menu.
Channel Lock This option allows you to prevent viewing of one or more channels. Press OK
to display the channel list and select with pq the channel you want to be
locked. Press GREEN to lock it. Consider the same procedure to lock other
channels if needed.
Parental Guidance Press OK to enter and set the age for suitable programmes for children, then
press pq.
5.7 Setup Menu
Language Select the Menu language of your choice. The default setting is English. Press
pq to select the menu language.
Audio Languages Press t u to select Primary for main audio track or Secondary next audio
channel if first is not available. Press pq t u to select your chosen Audio
Language, then press OK.
Subtitle Language Press pq t u to select your chosen Subtitle Language, then press OK
Country This item shows the region you been selected by first time you install the TV.
Restore Factory Default Press pq to select this function, by pressing OK and enter the PIN code. You
will reset all the settings contained in the main menu and deleted all installed
channels. TV will go back to First Time Installation See chapter 3.
Version Information Your current software version is displayed.
HDMI CEC See chapter 5.7.1.
Home /Shop Switch between Home modes and Shop modes with default more brightness
and Auto standby to off.
USB Clone This option allows you to copy you channel list to USB device as back up.
Insert USB device and select Back up. To load this later back into TV, select
“Restore”.
13
English

Strong SRT 40FB4003 Specifications

General

Screen shape	Flat
Response time	8.5 ms
Display diagonal	40 \
Display brightness	250 cd/m²
Display technology	LED
Native refresh rate	60 Hz
Contrast ratio (typical)	5000:1
Display diagonal (metric)	101 cm
Screen format adjustments	16:9
Motion interpolation technology	IQR (Image Quality Ratio) 100 Hz
3D	No
Battery type	AAA
Stand weight	100 g
Tuner type	Digital
Analog signal format system	Not supported
Digital signal format system	DVB-C, DVB-CI+, DVB-S2, DVB-T2
Operating system installed	-
RMS rated power	- W
Product color	Black
Panel mounting interface	200 x 200 mm
RF connector type	F, IEC
USB 2.0 ports quantity	1
S-Video inputs quantity	0
Power consumption (max)	74 W
Power consumption (standby)	0.5 W
Power consumption (typical)	54 W

Weight and Dimensions

Depth (with stand)	225 mm
Height (with stand)	526 mm
Weight (with stand)	3600 g
Depth (without stand)	63.9 mm
Width (without stand)	901 mm
Height (without stand)	511.3 mm
Weight (without stand)	3500 g
