3. 576i: for PAL system TV.
4. 576p: for PAL system TV.
5. 720p: for NTSC or PAL system TV.
6. 1080i: for NTSC or PAL system TV.
7. 1080p: for NTSC or PAL system TV.
TIP You can change the video resolution directly from viewing mode by
pressing the GREEN button on the remote control.
TV Format
Set the standard corresponding to your TV set. Available options are: PAL and NTSC.
Video Output
This setting is only relevant when the receiver is connected to the TV set via Scart. Select RGB for the
best picture quality or CVBS if your TV doesn’t support RGB.
7.3 Channel Search
To access the menu press MENU and select Channel Search. It contains two options: Dish setup and
DB (Data Base) Management. Select an option and press OK to enter it. Press to exit the menu.
7.3.1 Installation
7.3.1.1 Dish setup
Use p/q to highlight the satellite your dish is aimed at. Its antenna settings will be shown at the
right side. You can enter the right side with the tu buttons and return to the satellite list with .
7.3.1.2 Congure the antenna settings for the selected satellite
LNB Type: Press tu or OK to show the list of LNB Types. The Universal LNB
(09750/10600 MHz) is supported – the most used on the market. SatCR A
and SatCR B are used for SatCR systems. If only 1 SatCR LNB is connected,
use SatCR A. SatCR systems are mainly installed by professional experts. An
optional satellite splitter is required for multi-users.
LNB Power: Use tu to set the LNB power. 13/18V is the setting for a Universal LNB.
22KHz: Use tu to switch the 22KHz oscillator signal on or o. Auto is the setting for
a Universal LNB.
DiSEqC1.0: To select the correct port from up to 4 (if available) for the corresponding
LNB.
DiSEqC1.1: To select the correct port from up to 16 (if available) for the corresponding
LNB.
Motor: If using a motor driven dish, press tu to choose between DiSEqC1.2 and
DiSEqC 1.3 depending on the motor type you use.
