NOTE: Sunlight or very bright light might decrease the sensitivity of the remote
control.
3.0 CONNECTIONS
3.1 Basic connection using an HDMI cable
Fig.6
a) Connect the LNB of your satellite antenna to the SAT IN connector of your receiver using a good
quality coax cable and suitable ‘F-connector' plugs.
b) Connect one end of a good quality HDMI cable to the HDMI output on your receiver and the
other end to the HDMI input of your TV.
c) Plug the power adapter to a suitable wall outlet.
3.2 Basic connection using a Scart cable
Fig.7
a) Connect the LNB of your satellite antenna to the SAT IN connector of your receiver using a good
quality coax cable and suitable ‘F-connector' plugs.
b) Connect one end of a good quality Scart cable to the TV SCART connector on your receiver and
the other end to the SCART input of your TV.
c) Plug the power adapter to a suitable wall outlet.
3.3 Connecting multiple xed LNBs using a DiSEqC switch
Fig.8
a) Connect the LNBs of your xed antenna to the inputs of a DiSEqC switch
b) Connect the output or “to receiver” connector of the DiSEqC switch to the SAT IN connector on
your receiver.
c) Refer to section 3.1 or 3.2 for TV and mains connections.
3.4 Connecting to digital audio amplier
Fig.8
Connect one end of a good quality coaxial audio cable to the S/PDIF output of your receiver and the
other end to the coaxial audio input of your home theatre, amplier or any other device supporting
digital audio.
3.5 Connecting a USB storage device
Fig.8
NOTE: It is recommended to use USB 2.0 storage devices for recording and play
back of TV programmes or HD movies.*
7
