1550−470−6 Jack/Pump Motor Assembly
1550−470−7 Constant Flow Jack/Pump Motor Assembly
63
Item Part No. Part Name Qty. Item Part No. Part Name Qty.
A3−3 Hex Hd. Cap Screw 4 J 1550−71−8 Short Return Line 1
B3−121 Hex Washer Hd. Screw 4 K 1550−71−1 Long Pressure Line 1
C16−28 Nylock Nut 4 L (page 64) Jack Assembly 2
D30−40 E−A−R Grommet 4 (page 66) Constant Flow Jack Ass’y 2
E48−144 90 Elbow O−Ring Fitting 2 M 1550−270−60 Bottom Plate 1
F48−146 90 Elbow O−Ring Fitting 2 N 1550−271−2 Long Return Line 1
G 715−1−333 Rel. Valve Stop Sleeve 8 P 2025−75−84 Pump Motor Mtg. Bracket 2
H 2025−75−93 Short Pressure Line 1 R 2025−375−16 Pump Motor 1
