95
Fowler Only Quick Drop Assembly
Item Part No. Part Name Qty.
A 1550−33−28 Drive Bar Weldment 1
B 1550−33−14 Fow. Crkscr. Detent Ass’y 1
C 1550−33−25 Quick Drop Brkt. Ass’y, Rt. 1
D 1550−33−26 Quick Drop Brkt. Ass’y, Lt. 1
E 1550−33−19 Release Arm Weldment 1
F 1550−33−20 Handle Guard 2
G 1550−33−36 Release Label, Rt. 1
H 1550−33−37 Release Label, Lt. 1
J 1550−37−15 Fow. Emer. Drop Label, Lt. 1
K 1550−37−16 Fow. Emer. Drop Label, Rt. 1
L 1550−33−11 Spring/Cable Pin 1
M 1550−33−18 Cable Retainer 1
N 1550−33−16 Cable Return Arm 1
P 1550−33−29 Guide Spacer 2
R37−200 Handle Grip 2
S 1550−33−9 Fowler/Gatch Rel. Cable 1
T16−35 Nylock Nut 1
V14−21 Nylon Washer 3
W 1550−31−2 Threaded End Fitting 2
X 1550−31−1 Fowler Gas Cylinder 1
Y(page 98) Fowler Crankscrew Ass’y 1
Z(page 93) Gatch Crankscrew Ass’y 1
AA 1550−90−23 Fow. Q. Drop Reset Label 1
AB 1550−90−34 Gatch Engage Label 1
AC 4−5 Soc. Hd. Cap Screw 1
AD 4−29 Soc. Hd. Cap Screw 2
AE 16−47 Nylock Nut 1
AF 21−8 Set Screw 2
AG 38−285 Extension Spring 1
AH 38−284 Extension Spring 2
AJ 11−77 Washer 2
AK 14−55 Washer 4
AL 28−114 Retaining Ring 2
AM 16−28 Nylock Nut 4
AP 37−95 End Cap 1
AR 3−47 Hex Hd. Cap Screw 4
AS 25−79 Pop Rivet 10
AT 1550−34−22 Cable Guide 1
AV 59−75 Cable Tie 1
AX 16−36 Flexlock Nut 1
AY 3−68 Hex Hd. Cap Screw 1
AZ 4−108 Hex Hd. Cap Screw 1
BA 1710−34−127 Calf Stand Bar 1
BD 1001−34−29 Slider Support, Left 1
BE 1001−34−30 Slider Support, Right 1
