IInnssttaallllaattiioonn
IInnssttaalllliinngg tthhee ccoott ffaasstteenneerr
The Stryker cot fastener systems are compatible only with cots that conform to the installation specifications.
WWAARRNNIINNGG
• Always install the cot fastener by qualified personnel only. Improper installation could result in injury to the patient or
operator.
• Always make sure that all cots meet the installation specifications for the Stryker cot fastener system.
• Always adjust the rail clamp assembly to match the cot retaining post position for the cot manufacturer and model
number.
These instructions are intended for cots with antler style cot fastener systems. For crash-rated cot fasteners, see the
appropriate Operations Manual for installation instructions.
SSeelleeccttiinngg tthhee vveehhiiccllee ssaaffeettyy hhooookk
The vehicle safety hook is a device that ships with the cot. The cot safety bar and vehicle safety hook keep the cot from
being accidentally removed from the vehicle and provide increased operator assurance and confidence when loading and
unloading.
WWAARRNNIINNGG -- Always adjust the mounting location to maintain the proper position of the vehicle safety hook face when you
replace an existing vehicle safety hook with a new style.
NNoottee -- These instructions are intended for cots with antler style cot fastener systems. For crash-rated cot fasteners, see the
appropriate Operations Manual for installation instructions. Crash-rated cot fasteners are shipped and installed with
a vehicle safety hook, so no additional hook is needed.
The vehicle safety hook was designed for compatibility and proper operation when loading and unloading the cot from a
vehicle that is compliant with Federal Regulation KKK-A-1822. Stryker offers three different types of vehicle safety hooks
that are ordered and shipped with your cot. These vehicle safety hook types meet the needs of various emergency vehicle
configurations, specifically the length and location of the floor structure support that is located in the rear of the vehicle.
To select which vehicle safety hook is appropriate for your vehicle configuration:
• Consider the location of the floor structure support where there is adequate room to mount the vehicle safety hook.
• Mount the vehicle safety hook into the back of the vehicle. Provide bumper clearance to allow the operators to load and
unload the cot from the vehicle.
• Note the differences in vehicle design. Each vehicle safety hook provides a different mounting location option to
maintain the appropriate distance between the face of the vehicle safety hook and the edge of the door sill.
Due to the differences in vehicle dimensions and the floor structure support locations, each vehicle safety hook allows for a
different mounting location. Select the correct position for your vehicle safety hook installation.
•
Positioning of the vehicle safety hook, front to back
(page 11)
•
Positioning of the vehicle safety hook, side to side
(page 12)
6082-209-001 Rev AA.3 9 EN
