www.stryker.com KK-7100 REV 02 1-37
Accessories
Installing the oxygen bottle holder (Continued)
To install the oxygen bottle holder:
1. Insert the oxygen bottle holder into one of the two accessory sleeves near the head end (Figure 1-26 on page 1-37).
Figure 1-26: Installing the oxygen bottle holder
2. Rotate and lock the oxygen bottle holder into the accessory sleeve (Figure 1-27 on page 1-37).
Figure 1-27: Locking the oxygen bottle holder
Installing the foley bag basket
WARNING
Do not use accessories to support patient limbs or other body parts.
CAUTION
• The safe working load of each foley hook is 2 kg.
• Do not allow accessories to interfere with mechanical or electric mechanisms of the product.
To Next Page
