Strymon CONDUIT - MIDI Distribution: Connecting Controller; Step 2: Connect MIDI Controller to Conduit

Conduit - MIDI Hub
pg 11
9VDC
MIDI OUT MIDI IN
USB
SET
Connect a 5-pin DIN MIDI cable (not included) from the MIDI OUT
port of your MIDI controller or MIDI interface to the MIDI IN port
on Conduit.
2
MIDI CONTROLLER
MIDI OUT
MIDI IN
Connections – MIDI Distribution for a Pedalboard (cont.)
