Technical Data
9-3
#3758412 - Revision B - December, 2006
Model 700TR-3
REFRIG. (Upper)
REFRIG. (Lower)
CHARGE (R-134a Refrigerant)
NOTE: Always check serial tag for exact charge
NORMAL OPERATING PRESSURES
Low Side
High Side
COMPRESSOR
NOTE: Always check current parts price list for
possible substitutions.
Service Part No.
Manufacturer
Mfg. Model No.
Original Compressor/Service Compressor Amps
Original Compressor/Service Compressor BTU/H
DEFROST METHOD
DEFROST TERMINATOR
Cut-In Temp.
Cut-Out Temp.
DEFROST HEATER
Watts
Amps
Resistance/Ohms
DRAIN TROUGH HEATER
Watts
Amps
Resistance/Ohms
FILL TUBE HEATER
Watts
Amps
Resistance/Ohms
WATER VALVE
Watts
Amps
Resistance/Ohms (Inductive)
THERMISTORS
(Evap & Compartment) Resistance/Ohms at 32°F / 0°C
3.25 oz.
0-12 psi to 30-42 psi
75 psi to 110 psi
4201880
Embraco
EMI30HER
~1.0 / ~1.0
345 / 280
“Fan Assisted Off
Cycle Defrost”
Evap > 38°F before
Compressor ON; Fan ON
at high offset
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
30000 - 33000
3.75 oz.
0-12 psi to 30-42 psi
75 psi to 110 psi
4201880
Embraco
EMI30HER
~1.0 / ~1.0
345 / 280
“Fan Assisted Off
Cycle Defrost”
Evap > 38°F before
Compressor ON; Fan ON
at high offset
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
30000 - 33000
