Integrated
Integrated
(700-
(700-
3
3
T
T
ALL)
ALL)
Series
Series
Electronic Control System
3-3
#3758412 - Revision B - December, 2006
Figure 3-1. Basic 700TCI-3 Electronic Control System Diagram
BASIC ELECTRONIC CONTROL SYSTEM
Input operations for the electronic control system are performed at the control panel (located at the top of the upper
compartment), with monitoring, regulating and controlling functions taking place at the control board (located directly
behind the control panel). Temperatures and possible problems with the unit are illuminated in the control panel at
the LCD. This page illustrates a basic 700 Series electronic control system (Model 700TCI-3 used, See Figure 3-1).
The entire electronic control system is described in greater detail on the following pages.
SOL. MONITOR LINE
To Next Page
