Climate control panel
& Type A
1) Fan speed control dial (Refer to “Fan
speed control” F4-8.)
2) Temperature control dial (Refer to “Tem-
perature control” F4-7.)
3) Airflow control buttons (Refer to “Airflow
mode selection” F4-6.)
4) Air conditioner butto n (Refer to “Air
conditioner control” F4-8.)
5) Air inlet selection button (Refer to “Air
inlet selection” F4-8.)
6) Rear window defogger button (Refer to
“Defogger and deicer” F3-49.)
Climate control
4-3
– CONTINUED –
