Suffolk C-type - Page 29

1. BATTERY
2. MASTER KEY
3. STARTER SOLONOID
4. STARTER MOTOR
5. MAIN FUSE
6. AMMETER
7. REGULATOR
8. ALTERNATOR
9. STARTER BUTTON
10. IGNITION KEY
11. COIL
12. DISTRIBUTOR
13. SPOT LAMP
14. SPOT LAMP RELAY
15. COOLING FAN SWITCH
16. COOLING FAN
17. COOLING FAN RELAY
18. LOW CHARGE LAMP
19. OIL PRESSURE LAMP (OPTIONAL)
20. OIL PRESSURE SWITCH
21. TACHOMETER
22. VOLTAGE STABILISER
23. FUEL GAUGE
24. FUEL SENDER
25. FUEL PUMP SWITCH
26. FUEL PUMP
27. O/D GEARBOX SWITCH
28. O/D SOLONOID
29. FUSE BOX
30. FUSE BOX
31. SIDE LAMP SWITCH
32. HEADLAMP SWITCH
33. DIP/MAIN BEAM SWITCH
34. INDICATOR SWITCH
35. BRAKE LAMP SWITCH
36. OVERDRIVE SWITCH
37. HORN SWITCH
38. MAP/BONNET LAMP SWITCH
39. HORN
40. HORN
41. MAP LAMP
42. BONNET LAMP
43. L/F INDICATOR LAMP
44. L/F SIDE LAMP
45. L/F MAIN BEAM LAMP
46. L/F DIP BEAM LAMP
47. MAIN BEAM WARNING
48. R/F DIP BEAM LAMP
49. R/F MAIN BEAM LAMP
50. R/F SIDE LAMP
51. R/F INDICATOR LAMP
52. L/R INDICATOR LAMP
53. L/R SIDE LAMP
54. L/R BRAKE LAMP
55. R/R BRAKE LAMP
56. R/R SIDE LAMP
57. R/R INDICATOR LAMP
58. PANEL LAMPS
59. INDICATOR WARNING LAMP
60. L
/
R
S
I
D
E
L
A
SUFFOLK C-TYPE C TYPE WIRING DIAGRAM
COLOUR CODES
R = RED B = BLACK BL = BLUE BR = BROWN G = GREEN
W = WHITE Y = YELLOW PU = PURPLE P = PINK
