Section 3
SPECIFICATIONS
13
3.1 TABLE OF SPECIFICATIONS
LS--12 60 HZ (AIR-- OR WATER --COOLED) (I)
MODEL HP/KW CAPACITY LENGTH WIDTH HEIGHT (
V
I)WEIGHT(
V
I)dBA(
V
II) dBA (
V
II)
(ACFM/M
!
/MIN) (IN/MM) (IN/MM) (IN/MM) (LB/KG) w/ encl. / w/encl. /
w/o encl. w/o encl.
(air--cooled) (water--cooled)
-- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --------------------------------------------------------------------------------------------------------------
L (II) 40/30 90/5.38 72/1830 48/1220 60/1524 2060/934 83/89 77/82
50/37 235/6.65 72/1830 48/1220 60/1524 2060/934 84/89 76/83
-- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- ------------------------------------------------------------------------------------------------------------
H (III) 40/30 175/4.96 72/1830 48/1220 60/1524 2060/934 83/89 84/89
50/37 215/6.09 72/1830 48/1220 60/1524 2060/934 84/89 76/83
60/45 260/7.36 72/1830 48/1220 60/1524 2350/1066 85/90 77/84
LS--16 60 HZ (AIR-- OR WATER --COOLED) (I)
MODEL HP/KW CAPACITY LENGTH WIDTH HEIGHT WEIGHT dBA dBA
(ACFM/M
!
/MIN) (IN/MM) (IN/MM) (IN/MM) (LB/KG) w/ encl. / w/encl. /
w/o encl. w/o encl.
(air--cooled) (water--cooled)
-- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --------------------------------------------------------------------------------------------------------------
L 60/45 300/8.5 72/1829 48/1219 60/1524 2350/1066 84/89 82/89
75/55 370/10.4 72/1829 48/1219 60/1524 2680/1216 84/89 82/89
100/75 475/13.5 72/1830 48/1220 62.5/1588 2750/1247 84/89 83/85
-- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- ------------------------------------------------------------------------------------------------------------
H (II) 60/45 280/7.93 72/1830 48/1220 60/1524 2590/1175 84/89 82/89
75/55 330/9.34 72/1830 48/1220 60/1524 2680/1216 84/89 82/89
100/75 475/13.5 72/1830 48/1220 62.5/1588 2750/1247 84/89 83/85
ENCLOSURE
(OPT) (IV) 72/1829 48/1220 62/1588 500/227
-- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --------------------------------------------------------------------------------------------------------------
EES PACKAGE
(OPT) (IV)
89/2262 48/1220 130/2618 510/259
(I) Includes standard and 24KT. New series pressure range designations appearing after model number are as follows:
“L” -- 7.0 to 7.5 bar “H” -- 8.0 to 8.5 bar
(II) Model L Maximum Pressure: 110 psig/7.6 bar
(III) Model H Maximum Pressure: 125 psig/8.6 bar
(IV) The weights shown for the Enclosure and EES packages does not include the weight of the compressor package.
(V) An additional length of 4 in./102mm is needed for servicing the separator; 9 in./229mm for enclosure models.
(VI) Add 1450 lbs/658 kg for enclosure models.
(VII) Ratings for dBA at one meter.
COMPRESSOR: 24KT MODELS STANDARD MODELS
Type: Rotary Screw Rotary Screw
Standard Operating Pressure
(II):
100 psig (6.9bar) (L) 100 psig (6.9bar) (L)
115 psig (7.9bar) (H) 115 psig (7.9bar) (H)
Bearing Type: Anti---Friction Anti---Friction
Ambient Temperature (Max.)
(III):
105
_
F(41
_
C) 105
_
F(40
_
C)
Cooling: Pressurized Fluid Pressurized Fluid
Compressor Fluid: Sullair 24KT Coolant Fluid SRF1/4000 (12 & 16 Series
[60 & 75HP])
Sullube 32 (16 Series
[100HP])
Sump Capacity: 9.0 U.S. gallons (34 liters) 9.0 U.S. gallons (34 liters)
(40 and 50HP) (40 and 50HP)
10.0 U.S. gallons (38 liters) 10.0 U. S. gallons (38 liters)
(60 and 75HP) (60 and 100HP)
Control: Electro--- Pneumatic Electro--- Pneumatic
