Section 7
ILLUSTRATIONS AND PARTS LIST
34
7.3 MOTOR, FRAME, COMPRESSOR AND PARTS (LS---12 SERIES)
key part
number description number quantity
1 nut, hex 5/8” 824210---559 2
2 motor, 40HP (230/460V) 250016---692 1
S
motor, 50HP (230/460V) 250016---693 1
S
motor, 60HP (230/460V) 250016---694 1
3 support, motor (60HP) 250018---536 1
S
support, motor (40 and 50HP) 250017---490 1
4 nut, hex 3/8”---16 824206---337 12
5 washer, springlock 3/8” 837506---094 14
6 adapter, motor/compressor 250014---882 1
7 washer, springlock 5/8” 837510---156 10
8 capscrew, hex 5/8” --- 11 x 1 1
/2
” 828610---150 4
9 screw, hex serrated washer 5/16” x 3/4” 829705---075 3
10 guard, coupling 250018---412 1
11 capscrew, ferry 1/2”---13 x 2 1/2”
(40 and 50HP) 828408---250 6
S
capscrew, ferry 5/8”---11 x 2 3/4” (60HP) 828410---275 6
12 washer, springlock 1/2” (40 and 50HP) 837508---125 6
S
washer, springlock 5/8” (60HP) 837510---156 6
13 washer, conduit reducing 3” x 1 1/2” 847012---060 2
14 hub, coupling (40 and 50HP) 250018---005 1
S
hub, coupling (60HP) 250018---008 1
15 element, coupling (40 and 50HP) 250004---641 1
S
element, coupling (60HP) 250018---551 1
16 hub, coupling (40 and 50HP) 250004---642 1
S
hub, coupling (60HP) 250018---006 1
1 7 c ompr essor unit
(I)
Consul t Fac tor y 1
18 capscrew, hex 3/8”---16 x 2 1/4 828606---225 12
19 grip, cord 250014---557 1
20 wire, type g---gc 4 ga 250014---306 4 ft.
21 support, compressor 250017---489 1
22 capscrew, hex 5/8”---11 x 1 1/4” 828610---125 6
23 frame, main 250015---817 1
(Continued on page 37)
(I)
There is an exchange program whereby a remanufactured compressor unit can be obtained from Sullair
distributors or the factory at less cost than the owner could repair the unit. For information regarding the
unit exchange program, contact your nearest Sullair representative or the Sullair Corporation.
Theshaft seal isnotconsidered partofthecompressor unitinregard tothe 2year warranty,but the normal
Sullair parts warranty applies. Forshaft seal repairs, order shaft seal repair kit no. 02250050---363 (12Se-
ries 40 and 50HP) or kit no. 02250050---364 (12 Series 60HP), and seal tool kit no. 602542---001.
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR.
