Section 7
ILLUSTRATIONS AND PARTS LIST
42
7.6 A IR INLET SYSTEM (LS --- 12 AND LS --- 16 SERIES)
key part
number description number quantity
1 filter, assembly air (with flanged base)
(I)
250020---315 1
2 capscrew, hex 1/2 ”---13 x 2 1/2” 828608---250 4
3 washer, springlock 1/2” 837508---125 4
4 connector, tube---straight 1/8”npt x 1/4”t 813604---125 1
5 tubing, thermoplastic 1/4”od 250024---745 7 ft.
6 gasket,1/32 ” x 51/4
!
”od x 4 1/8”id 040708 2
7 lever, inlet valve 020687 1
8 screw, set 5/16”---18 x 3/4 ” 408383 1
9 valve, butterfly 4” 040640 1
10 adapter, compressor inlet assy 02250046---257 1
11 clamp, hose 040642 1
12 elbow, rubber reducing 4” x 5” 047275 1
13 clamp, hose 6” 408153 3
14 tube, aluminum 5” x 23” 02250046---003 1
15 hose, hump 5” 02250045---989 1
16 screw, hex serrated wash 5/16” x 3/4” 829705---075
17 support, bracket filter 02250046---997 1
18 nut, hex flanged 5/16”---18 825305---283 1
19 band, mounting 12” 040081 2
20 filter, assy air (16 Series 100HP)
(II)
02250045---855 1
S
filter, assy air (12 Series 40 and 50HP)
(III)
049103 1
S
filter, assy air (12 Series 60HP;
16 Series 60 and 75HP)
(IV)
047274 1
(I)
For maintenance on air filter assembly no. 250020---315, order element no. 040899.
(II)
For maintenance on air filter assy no. 02250045---855, order primary element no. 02250046---012, and
safety element no. 02250046---013.
(III)
For maintenance on air filter assembly no. 049103, order element no. 049301.
(IV)
Formaintenance onairfilterassembly no.047274,orderprimaryelement no. 047542and safety element
no. 047543.
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR.
