Sullair LS-12 User Manual

Section 7
ILLUSTRATIONS AND PARTS LIST
72
7.13 COMPRESSOR DISCHARGE SYSTEM (LS---12 AND LS---16 SERIES)
key part
number description number quantity
1 nipple, pipe 1/4” x 2” (12 Series) 823104---020 1
S
nipple, pipe 1/4” x 1 1/2” (16 Series) 823104---015 1
2elbow,pipe90
_
1/4” 801515---010 2
3 nipple, pipe xs 1/4” x close 823204---000 5
4 tee, pipe galvanized 1/4” 804415---010 1
5 orifice, secondary 1/32” 040381 1
6 orifice, primary 3/32” 022033 1
7 strainer, v---type
(I)
241771 2
8 glass, sight 046559 2
9 connector, tube 1/4” x 1/4” 810204---025 3
10 tube, 1/4” 841015---004 10.5 ft.
11 spring, discharge valve 233615 1
12 disc, discharge valve 013549 1
13 valve, relief 175 psig (12.1 bar) 248344 1
14 washer, springlock regular 5/8” 837510---156 8
15 capscrew, hex 5/8”---11 x 2” gr8 828210---200 8
16 valve, minimum pressure/check
(12 Series)
(II)
241581 1
S
valve, minimum pressure/check
(16 Series)
(III)
250016---618 1
17 nipple, pipe xs 1 1/4” x close (12 Series) 822220---000 1
S
nipple pipe xs 1 1/2” x close (16 Series) 822224---000 1
18 bushing, reducing hex 1 1/2” x 1 1/4”
(12 Series only) 802106---050 1
19 elbow, tube---m 1/4” x 1/4” 810504---025 3
20 bushing, reducing hex 1 1/2” x 1/4” 802106---010 1
21 cross, pipe 1 1/2” 801315---060 1
22 nipple, pipe 1 1/2” x close 822224---000 1
23 bushing, reducing hex 1 1/2” x 1/2” 802106---020 1
24 nipple, pipe 1/2” x close 822208---000 1
25 elbow, pipe 90
_
1/2” 801515---020 2
26 nipple, pipe 1/2” x 7” 822108---070 1
27 valve, blowdown 1/2” npt
(IV)
250030---276 1
28 bushing, reducing 1/2” x 1/4” 802102---010 2
(Continued on page 75)
(I)
For maintenance on v---type strainer no. 241771, order repair kit no. 241772.
(II)
For maintenance on minimum pressure/check valve no. 241581, order repair kit no. 250026---758.
(III)
For maintenance on minimum pressure/check valve no. 250016---618, order repair kit no. 250019---444.
(IV)
For maintenance on blowdown valve no. 250030---276, order repair kit no. 02250045---132.
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR.
