Sullair LS-12 User Manual

Section 7
ILLUSTRATIONS AND PARTS LIST
74
7.13 COMPRESSOR DISCHARGE SYSTEM (LS---12 AND LS---16 SERIES) (CONTINUED)
key part
number description number quantity
29 orifice, 1/2”m x 1/2”f x .156 234125---156 1
30 silencer, air 1/2” 041006 1
31 gauge, fluid level without ball check 046558 1
32 plug, o---ring boss sae 1 1/4” 040029 1
33 adapter, filler 020044 1
34 elbow, pipe 1 1/2” 801515---060 1
35 tank, receiver separator 250015---284 1
36 element, separator (primary)
(V)
250034---115 1
37 capscrew,1/2 hex ”---13 x 1 1/2” 828608---150 4
38 washer, springlock regular 1/2 ” 837508---125 4
39 tee, tube---m 1/4” x 1/4” 810904---025 1
40 capscrew, ferry 3/8” ---16 x 1” 828406---100 1
41 nipple, half 2 1/2” x 3” 822840---030 1
42 coupling, flexible 21/2” (STD)
(VI)
040648 1
S
coupling, flexible 2 1/2” (KT)
(VII)
250007---563 1
43 nipple, half 2 1/2” x 4” 822840---040 1
44 tee, reducing 2 1/2” x 1/2” x 2 1/2” (12 Series) 802210---020 2
S
tee, reducing 2 1/2” x 1/2” x 2 1/2” (16 Series)802210---020 2
45 gauge, temperature 2” 042582 1
46 connector, flex 1/4”t x 1/4”p 020169 1
47 nipple, pipe 2 1/2” x 6” (12 Series) 822140---060 1
S
nipple, pipe 2 1/2” x 5 1/2” (16 Series) 822140---055 1
48 switch, temperature 240
_
F nc 040588 1
49 coupling, conduit rigid 1/2” 250007---179 1
50 elbow, 90
_
lg---tite 1/2” 846600---050 1
51 conduit, csa flex 1/2” 846315---050 2 ft.
52 element, separator (secondary)
(VIII)
250042---861 1
53 washer, pl---b regular unfinished 1/2” 837208---112 4
54 nipple, pipe 1 1/2” x 3” 822124---030 1
55 capscrew, ferry 3/8”---16 x 3 1/4” 828406---325 3
56 adapter, discharge (12 Series only) 012883 1
57 gasket, discharge valve (12 Series only) 040541 1
58 body, discharge valve assembly
(12 Series only) 013605 1
59 plug, pipe 1/2” 807800---020 2
(V)
For maintenance primary separator element no. 250034---115, order repair kit no. 250034---116.
(VI)
For maintenance on flexible coupling no. 040648, order repair kit no. 040649 (2 required).
(VII)
For maintenance on flexible coupling no. 250007---563, order repair kit no. 250007---564
(2 required).
(VIII)
For maintenance on secondary separator element no. 250042---861, order repair kit no.
250042---862.
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR.
