Sullair LS-12 User Manual

Section 7
ILLUSTRATIONS AND PARTS LIST
84
7.16 INSTRUMENT PANEL AND PARTS (LS---12 AND LS---16 SERIES)
key part
number description number quantity
1 union, tube 1/4” x 1/4” 811104---025 5
2 screw, tc---f pan #8---32 x 1/2” 835601---050 4
3 tubing, 1/4” 841015---004 10 ft.
4 connector, tube---f 1/4” x 1/8” 810104---012 5
5 tee, tube---f 1/4” x 1/8” 811004---012 1
6 connector, tube---f 1/4” x 1/8” 250025---327 1
7 angle, instrument panel 02250044---407 1
8 hose, nylon 1/4” 842215---004 6 ft.
9 panel, instrument 250019---481 1
10 decal, instrument panel 02250051---301 1
11 gauge, differential pressure 0---30 psi
(0---2.1 bar) 250003---799 1
12 gauge, vacuum 0---30 water 250003---797 1
13 gauge, differential pressure 0---15 psi
(0---1 bar) 250003---798 1
14 gauge, pressure 2” diameter 250005---185 2
15 gauge, temperature 2” 042582 1
16 switch, pushbutton START 250016---351 1
17 switch, pushbutton STOP 250016---350 1
18 panel, electrical 250015---471 1
19 gasket, hourmeter 410353 1
20 hourmeter, 60 Hz 250015---715 1
S
hourmeter, 50 Hz 250042---010 1
21 nut, hex washer 1/4” 825304---236 1
22 decal, electrical panel 02250051---388 1
23 holder, pilot lamp 043383 1
S
lens, green 043385 1
S
lens, r ed 043384 1
S
lens, amber 047016 1
S
bulb, pilot lamp 043386 1
24 support, instrument panel 02250044---405 1
25 screw, hex ser washer 5/16” x 3/4” 829705---075 1
26 screw, hex ser washer 1/4” x 3/4” 829704---075 1
27 nut, hex washer 5/16” 825305---283 1
28 switch, sel 2 pos 250016---352 1
29 support, inst panel 250038---097 1
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR.
