Section 7
ILLUSTRATIONS AND PARTS LIST
92
7.19 CANOPY ENCLOSURE AND PARTS (LS---12 AND LS---16 SERIES)
key part
number description number quantity
1 panel, enclosure end (water---cooled) 250018---647 2
S
grille, cooler (60 and 75HP) 250018---296 1
2 angle, seal (40 and 50HP) 250018---291 2
S
angle, seal (60 and 75HP) 250018---106 2
S
angle, seal (100HP) 02250060---870 2
3 angle, seal (40 and 50HP) 250018---291 1
S
angle, seal (60 and 75HP 250034---881 1
S
angle, seal (100HP) 02250060---871 2
4 screw, hex serrated washer 5/16”---18
(water---cooled) 829705---075 44
S
screw, hex serrated washer 5/16”---18
(air---cooled) 829705---075 40
5 clamp, wire (air---cooled) 043194 16
6 frame, roof (40 and 50HP) 250018---268 1
S
frame, roof (60 and 75HP) 250017---865 1
S
frame, roof (100HP) 02250043---154 1
7 panel, access roof 250017---309 1
8 panel, fiberglass roof 250020---012 1
9 nut, hex flange 5/16” (air---cooled) 825305---283 4
S
nut, hex flange 5/16” (water---cooled) 825305---283 12
10 wire, neoprene #16---4 850604---016 8
11 nut, retainer 5/16”---18 861505---140 16
12 panel, corner --- right hand 250018---609 2
13 panel, front side 250017---311 1
14 latch, adjustable trigger lock 049764 6
15 panel, back side 250017---312 1
16 washer, springlock 1/4” 837504---062 12
17 nut, hex 1/4” 824204---226 12
18 grille, enclosure end (air---cooled) 250018---667 2
19 panel, corner --- left hand 250018---610 2
20 nut, hex flanged 5/16” (water---cooled) 825305---283 16
S
nut, hex flanged 5/16” (air---cooled) 825305---283 20
21 panel, fiberglass door 250020---015 12
22 panel, access side 250017---310 4
23 capscrew, hex 1/4”---20 829104---100 8
24 panel, end 250018---646 2
25 nut, retainer 5/16”---18 861405---092 8
26 felt, weatherstrip 043502 92 ft.
27 guard, fan 20” 241137 1
28 washer, plain 5/16” 838205---071 8
29 panel, access roof 250017---308 1
(Continued on page 95)
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR.
