SECTION 7 TS20C USER MANUAL
121
Compressor Shuts Down With
Air Demand Present
P1 is less than 10 psig (0.7 bar)
(P1 low display)
First, check starter wiring. If discharge
pressure is above 10 psig (0.7 bar) was
evident, then sensor is at fault—check
connections from transducer. If adequate,
replace transducer.
Compressor will not build up full
discharge pressure
Air demand is too great Check service lines for leaks or open valves.
Dirty air filter Check for filter maintenance message on
Supervisor™ panel and change or clean
element if required.
Pressure Regulator Out of
Adjustment
Adjust regulator according to control
adjustment instructions in the Maintenance
Section.
Defective Pressure Regulator Check diaphragm and replace if necessary (kit
available).
Broken Sullicon Spring Replace.
Line pressure rises above
unload P2 pressure setting on
the Supervisor™
Leak in control system causing
loss of pressure signals
Check for leaks.
Defective solenoid valve Check that Sullicon control lever is moved to
unload stop when Supervisor™ is in NO LOAD
mode. Repair or replace if necessary (kit
available).
Defective blowdown valve Check that sump pressure is exhausted to the
atmosphere when in the OFF LOAD mode.
Repair or replace if necessary (kit available).
Ruptured Sullicon control
diaphragm
Replace.
Plugged control line filter. Clean or repair if necessary.
Excessive Fluid Consumption Clogged return line strainer or
orifice
Clean strainer (screen with o-ring replacement
kit available).
Clean orifice.
Separator element damaged or not
functioning properly
Check separator differential (plugged) dP1.
Leak in the lubrication system Check all pipes, connections and components
Excess fluid foaming Drain and change.
Fluid level too high Drain excess fluid.
Pressure Relief Valve Opens
Repeatedly
Defective pressure relief valve Replace pressure relief valve.
VSD Fault Code — Refer to Supervisor™ Manual
Table 7-1: Troubleshooting Guide
