Sullair TS20C User Manual

SECTION 2 TS20C USER MANUAL
29
Figure 2-10: TS20C Piping and Instrumentation 200-250HP
KEY
NO.
PART NO.
Q
T
Y
DESCRIPTION
1 02250140-798 1 FILTER,INL OPTIMALAIR 16" DIA.
2 02250161-157 1 VALVE,INLET 8” W/ALUM SLV
3 - 1 COMPRESSOR,UNIT TS20C
4 - 1 VALVE,SPIRAL
5 TNK,SEP 1 TANK,FLUID/AIR SEPARATOR (SEE TAB)
6 250034-121 1 ELEMENT,PRIMARY
7 250034-133 1 ELEMENT,SECONDARY
8 VLV,RLF 1 VALVE,RELIEF (SEE TAB)
9 02250097-611 1 PLUG,SIGHT GLASS 1-7/8” SAE
10 02250179-296 1 VALVE,BALL 1-1/16” SAE x 3/4” NPT
11 250033-821 1 VALVE,MIN. PRESSURE CHECK 3” NPT
12 02250173-053 1 COOLER,COMBO FLUID/AIR W/SAE FLUID
PORTS
13 02250166-743 1 SEP,WTR SCWS-1700N 2-1/2” L/AD
14 02250127-119 1 HSG,THRMVLV 1-7/8” SAE 4 PORT
15 02250121-656 1 FILTER.FLUID SAE 2” FLG CORELESS
16 02250113-668 1 VALVE,FLUID STOP 1-5/8” SAE PORTS
17 02250155-174 4 XDCR,PRESS 0-250# RATIOMETRIC
18 02250175-087 5 P,THERMISTER 3000 OHM NTC 12’L
19 02250101-191 2 ORIFICE, .03” (.76mm)
20 02250125-774 1 ORIFICE .031” (.79mm)
21 02250125-775 1 ORIFICE, .062” (1.58mm)
22 02250132-934 1 ORIFICE,CAP 1/4” NPT .031” DIA. (.79mm)
23 02250051-913 1 VLV,RLF INTERSTAGE 65#
24 02250186-328 1 VLV,PRESSURE REG 65PSI
25 02250126-129 2 GLASS,SIGHT 1/4”
26 02250117-782 2 STRAINER,V-TYPE 1/4” 300PSI (2.1 BAR)
PLEASE NOTE: WHEN ORDERING PARTS,
INDICATE SERIAL NUMBER OF COMPRESSOR
27 42694 1 VALVE,CHECK 1/2”
28 02250110-557 3 VALVE,CHECK 1/4”
29 02250148-608 1 VALVE,PRESSURE REG. 1/4” NPT 70-25-#
30 02250052-358 1 VALVE,REGULATOR BACKPRESSURE CTL
1/4”
31 02250046-568 1 VALVE,REGULATOR REDUCING 1/4” NPT
32 02250100-042 1 VLV, 1/2 BLDWN 1.8:1 250 PSIG
33 02250125-657 2 VALVE,SOLENOID 1/4” NPT 3WNO 115VAC
34 02250125-665 1 VLV,SOL 3WNC 1/4 210# N4
35 02250170-782 1 VLV,DR COMBO 115 VAC
36 02250182-548 1 VLV,BALL/STNR COMBO-1/2”NPT
37 02250153-023 1 FLTR,SCF-20N 1/4” NPT
38 02250117-009 1 GAGE,PRESSURE 1/4” NPT 0-200PSI
39 02250078-249 1 SWITCH,VAC 22” W.C. N4 (555.8mm W.C.)
40 02250182-545 1 DRN,ZERO LOSS 110V 1/2”NPT
41 02250177-841 1 SA,DISCH CHK VLV TS20C
42 02250043-014 1 HTR,SUMP 1800W 120V PAD 29X19
43 02250087-631 1 HEATER,MOIST SEPARATOR 120VAC 70W
44 02250125-673 1 VALVE,SOLENOID 1/4” NPT 4-WAY EES
45 02250118-585 2 ORIFICE, .062” .25” FNPT x .25” MNPT
46 241906 2 CYLINDER,PNEU 7/8” DIA x 4” STROKE
Continued on page 31
KEY
NO.
PART NO.
Q
T
Y
DESCRIPTION
PLEASE NOTE: WHEN ORDERING PARTS,
INDICATE SERIAL NUMBER OF COMPRESSOR
