Operation & Maintenance Manual 39
Cyclo® BBB4
Cyclo® BBB4
Y2 Oil Fill & Drain Procedures, continued
Oil Drain Process
* All oil quantities are estimates
Table 33. BBB4 Y2 Single Reduction Oil Quantity*
Bevel Gear Unit Size
Y2 Configuration Oil Quantity
gallon liter
4A10
0.84 3.17
4A11 0.86 3.26
4A12 0.89 3.35
4A14 0.99 3.77
4B12 1.71 6.50
4B14 1.84 6.97
4B16 2.01 7.61
4C14 2.93 11.1
4C16 3.12 11.8
Bevel Gear Unit Size
Y2 Configuration Oil Quantity
gallon liter
4C17
3.30 12.5
4D16 5.26 19.9
4D17 5.42 20.5
4D18 5.55 21.0
4E17 7.61 28.8
4E18 7.69 29.1
4E19 8.03 30.4
4F18 10.4 39.4
4F19 10.7 40.6
Table 34. BBB4 Y2 Double Reduction Oil Quantity*
Bevel Gear Unit Size
Y2 Configuration Oil Quantity
gallon liter
4A10DA
0.85 3.2
4A12DA 0.89 3.38
4A12DB 0.91 3.43
4B12DA 1.73 6.53
4B12DB 1.74 6.57
4B14DA 1.85 7.00
4B14DB 1.86 7.04
4C14DA 2.96 11.2
4C14DB 2.96 11.2
4C14DC 2.99 11.3
Bevel Gear Unit Size
Y2 Configuration Oil Quantity
gallon liter
4C16DA
3.12 11.8
4C16DB 3.14 11.9
4C17DA 3.33 12.6
4D16DA 5.29 20.0
4D16DB 5.29 20.0
4D17DB 5.44 20.6
4D17DC 5.47 20.7
4E17DA 7.61 28.8
4E17DB 7.63 28.9
4E17DC 7.66 29.0
