Sumitomo Cyclo BBB4 - Page 52

Unit
Size
Reduction Ratio Part Numbers
Overall Cyclo®
Input
Kit
Reduction
Kit
4A12 4B12
Bevel Pin
Carrier
Bevel Pin
Carrier
4A120
4A125
4B120
4B125
19, 21 6
D78623
D78690
CJ691LG CJ693LG
22, 25 7
See Note
[1]
26, 28 8 D78691
35, 39 11 D78692
42, 46 13 D78693
48, 53 15 D78694
54, 60 17 D78695
67, 74 21 D78696
80, 88 25 D78697
93, 102 29 D78698
112, 123 35 D78699
138, 151 43 D78700
163, 179 51 D78701
189, 207 59 D78702
227, 249 71 D78703
278, 305 89 D78704
364 104
See Note
[1]
364, 417 119
See Note
[1]
> 424 > 121
See Note
[1]
Table46.Cyclo®BBB4ReductionComponentsPartNumbers(Ratios>19:1),continued
Unit
Size
Reduction Ratio Part Numbers
Overall Cyclo®
Input
Kit
Reduction
Kit
4A14 4B14 4C14
Bevel Pin
Carrier
Bevel Pin
Carrier
Bevel Pin
Carrier
4A140
4A145
4B140
4B145
4C140
4C145
19, 21 6
D78623
D78535
CJ692LG CJ694LG CJ696LG
22, 25 7
See Note
[1]
26, 28 8 D78536
35, 39 11 D78537
42, 46 13 D78538
48, 53 15 D78539
54, 60 17 D78540
67, 74 21 D78541
80, 88 25 D78542
93, 102 29 D78543
112, 123 35 D78544
138, 151 43 D78545
163, 179 51 D78546
189, 207 59 D78547
227, 249 71 D78548
278, 305 89 D78549
364 104
See Note
[1]
364, 417 119
See Note
[1]
> 424 > 121
See Note
[1]
Unit Size
Reduction Ratio Part Numbers
Overall Cyclo®
Input
Kit
Reduction
Kit
4B16 4C16 4D16
Bevel Pin
Carrier
Bevel Pin
Carrier
Bevel Pin
Carrier
4B160
4B165
4C160
4C165
4D160
4D165
19, 21 6
D78625
D78720
CJ695LG CJ697LG CJ699LG
22, 25 7
See Note
[1]
26, 28 8 D78721
35, 39 11 D78722
42, 46 13 D78723
48, 53 15 D78724
54, 60 17 D78725
67, 74 21 D78726
80, 88 25 D78727
93, 102 29 D78728
112, 123 35 D78729
138, 151 43 D78730
163, 179 51 D78731
189, 207 59 D78732
227, 249 71 D78733
278, 305 89 D78734
364 104
See Note
[1]
364, 417 119
See Note
[1]
> 424 > 121
See Note
[1]
Unit
Size
Reduction Ratio Part Numbers
Overall Cyclo®
Input
Kit
Reduction
Kit
4C17 4D17, 4E17
Bevel Pin
Carrier
Bevel Pin
Carrier
4C170
4C175
4D170
4D175
4E170
4E175
19, 21 6
D78626
D78735
CJ698LG CJ700LG
22, 25 7
See Note
[1]
26, 28 8 D78794
35, 39 11 D78736
42, 46 13 D78737
48, 53 15 D78738
54, 60 17 D78739
67, 74 21 D78740
80, 88 25 D78741
93, 102 29 D78742
112, 123 35 D78743
138, 151 43 D78744
163, 179 51 D78745
189, 207 59 D78746
227, 249 71 D78747
278, 305 89 D78748
364 104
See Note
[1]
364, 417 119
See Note
[1]
> 424 > 121
See Note
[1]
Unit Size
Reduction Ratio Part Numbers
Overall Cyclo®
Input
Kit
Reduction
Kit
4D18 4E18 4F18
Bevel Pin
Carrier
Bevel Pin
Carrier
Bevel Pin
Carrier
4D180
4D185
4E180
4E185
4F180
4F185
19, 21 6
D78627
See Note
[1]
CJ655LG CJ657LG22, 25 7
See Note
[1]
26, 28 8
See Note
[1]
35, 39 11 D78749
CK012LG CK016LG
42, 46 13 D78750
48, 53 15 D78751
54, 60 17 D78752
67, 74 21 D78753
80, 88 25 D78754
93, 102 29 D78755
112, 123 35 D78756
138, 151 43 D78757
163, 179 51 D78758
189, 207 59 D78759
227, 249 71 D78760
278, 305 87 D78761
Unit
Size
Reduction Ratio Part Numbers
Overall Cyclo®
Input
Kit
Reduction
Kit
4E19 4F19
Bevel Pin
Carrier
Bevel Pin
Carrier
4E190
4E195
4F190
4F195
19, 21 6
D78628
See Note
[1]
CJ956LG CJ931LG
22, 25 7
See Note
[1]
26, 28 8 See Note
[1]
35, 39 11 D78763
42, 46 13 D78763
48, 53 15 D78764
54, 60 17 D78765
67, 74 21 D78766
80, 88 25 D78767
93, 102 29 D78768
112, 123 35 D78769
138, 151 43 D78770
163, 179 51 D78771
189, 207 59 D78772
227, 249 71 D78773
278, 305 87 D78774
Parts, continued
Cyclo® Reduction Component Parts
Note: [1] Consult Factory
Operation & Maintenance Manual 51
Cyclo® BBB4
