Service Manual SummaSign
REMOVING THE BOTTOM PLATE
To remove the bottom plate, proceed as follows:
8.
9. Turn the unit upside down.
10.Remove the screws holding the bottom plate in place (the number of screws varies depending on
the cutter type).
11.Remove the bottom plate.
12.The bottom plate has an additional front and rear plate that can be removed without having to
remove any screws. Pay close attention to how the plates are positioned, because they will have
to be returned to their original location when re-installed.
To re-install, proceed in the reverse order of removal. Make sure to firmly tighten all screws.
7. Note:
8. Make sure the bottom plate is placed correctly into the slot of the front plate
and the rear plate .
9.
10.
REPLACING THE CAM ROLLERS
To replace the cam rollers, proceed as follows:
13.Remove the set screw on either side of the cam rollers .
14.Remove the cam roller shaft (push against the left side of the shaft).
15.Remove the cam roller.
16.
11. Note:
12. a. Cam rollers come in pairs. When one is malfunctioning or broken, both cam
rollers need to be replaced.
13. b.The models 750, 1010 and 1300 have three cam rollers. The centre cam roller
is not matched with the two outer cam rollers and can be installed independently.
To re-install, proceed in the reverse order of removal. Make sure to firmly tighten all screws.
14. Note:
15. It is extremely important that the cam roller be stable and stationary. To
achieve this, press one side of the camshaft while tightening the set screws.
Replacement Guidelines 2-5
