10-9
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments,
controls and other places on tractor. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Fuel Level
Engine Rotational Speed
Parking Brake
Air Cleaner Clogging Sensor
Battery Charging Condition
Engine Oil-Pressure
Turn Signal
Power Take-Off Clutch Control-Off Position
Power Take-Off Clutch Control-On Position
Hazard Warning Lights
Master Lighting Switch
Headlight-Low Beam
Headlight-High Beam
Audible Warning Device
Four-Wheel Drive-On
Four-Wheel Drive-Off
Engine Coolant-Temperature
Slow
Fast
Parking Brake Indication
PTO 540
540
Read Operator's Manual
Engine Speed Control
Differential Lock
Hydraulic Control-Lowered Position
Hydraulic Control-Raised Position
Remote Cylinder-Retract
Remote Cylinder-Extend
Engine Stop
Universal Symbols
INTRODUCTION & IDENTIFICATION
