INSTRUMENTS & CONTROLS
This switch is used to ON/OFF the PTO & provide signal to
PTO solenoid valve through safety controller. When the PTO
switch pressed for 03 seconds the PTO will be ON. Pressing
the switch again will stop the PTO and it may continue spin for
sometimes in no load condition.
This switch is to turn the cruise control on and off. Press in
upper part of switch to activate and the lower side to
deactivate cruise control.
Never install a wire or larger ampere fuse instead of
recommended fuse.
CAUTION
Fig. 3.3.6
The fuse box is mounted on radiator bracket (see figure). If
any electrical failure occurs, check and rectify the problem &
replace the blown fuse with genuine fuse of specified rating.
PTO ON-OFF Switch
Cruise ON-OFF Switch
Fuse Box
30-10
