Summit TX25H - Instrument Cluster Indicators

Instrument Cluster
Fig. 3.2
5
87
10
11
12
13
14
15
1
3
4
2
96
3 Air Cleaner Clogging Indicator
4 Left Turn Indicator
7 High Beam Indicator
2 Battery Charging Indicator
5 RPM & Hour Meter
8 Glow Plug Indicator
9 Oil Pressure Indicator
10 PTO Monitor Lamp
6 Right Turn Indicator
1 Parking Brake Indicator
11 Turn Trailer Indicator
12 Temperature Gauge
15 Cruise On-Off Indicator
14 Working Lamp Indicator
13 Fuel Gauge
1
30-2
