Hand throttle lever (D) mounted on front panel is used in field
application. To increase the speed of engine, push the lever
up and to decrease, pull the lever down.
Hand Throttle Lever
OPERATION
D
Differential Lock
Press differential lock pedal (E) to rotate both the wheels at
same speed.
IMPORTANT: Differential lock should only be used when
traveling in a straight line. The differential lock should be
disengage when turning the tractor to avoid damage to the
differential assembly.
WARNING
Do not apply differential lock while tractor speed
is more than 3.73 mph [6 kmph] on turning.
PTO ON-OFF Switch :
This switch is used to ON/OFF the PTO operation. This
switch gives signal to PTO solenoid valve through safety
controller. Press the switch for 03 seconds to engage the
PTO & re-press the switch to stop the PTO.
PTO shaft may continue spin for sometimes in no load
condition.
40-6
E
