Summit TX25H - Tractor Lights and Connections

INSTRUMENTS & CONTROLS
Turn/Hazard Signal Lights (5): These lights are fitted on ROPS as shown in figure.
Tail Lights (2): Tail lights are having various indications i.e. light indication for brakes and turn signal.
Work Lamp (4): Adjustable work lamp is provided at rear side as shown in figure.
Registration Plate Light (3): Registration plate light is provided on registration plate at rear side as shown in
figure.
Head Lights (1): Projector lamps are provided for better focus & lighting and improve aesthetics.
Tractor Lights - SUMMIT TX25
2
2
4
1
3
30-11
5
5
