Summit TX25H - Battery; Seven Pin Socket

INSTRUMENTS & CONTROLS
Battery is located at front side of tractor on front axle bracket.
Open the hood to access the battery.
Battery
Seven pin socket mounted on licence plate to attach the
trailer connections.
Details of connectors is given under:
Seven Pin Socket:
30-12
Pin No
Pin 2
Pin 4
Pin 5
Pin 6
Pin 3
Pin 7
Pin 1
Ground
Right Parking Light
Used for
Left Turn Single
Rear Fog light / Aux +ve
Right Turn Signal
-
Brake Light
Brown
-
Wire Color
Yellow
Blue
White
Green
Red
