Summit TX25H - Wheels, Tires, and ROPS Operation

Recommended Tire Pressure : Front: 20~22 P.S.I / Rear: 14~16 P.S.I
Correct Pressure Insufficient Pressure Over Pressure
Good adherence by dirt grousers.
Good cleaning of the tread
Reduce adherence through lack of
tire grip.
Deterioration of tire casing by
traction forces.
Reduce grip due to lack of
cleaning
Deterioration due to compacted
ground.
Wheels and Tires
40-12
Check Torque of Front and Rear Wheel Hardware
A
B
Check the torque of the front wheel rim (A) and rear wheel
rim (B), tighten to the specifications:
Front wheel rim: 53 lbf-ft [72 Nm]
Rear wheel rim: 103 lbf-ft [130 Nm]
