Summit TX25H - Dashboard Switches and Controls

INSTRUMENTS & CONTROLS
Hazard Warning Light Switch :
Purpose of the hazard switch is as follows.
1. All the four lights blinking, indicates that driver has no
control on tractor.
2. Mechanical defects in the tractor.
Push this switch to blink all indicators in HAZARD situation
to alert others.
Dashboard Controls :
Combination Switch :
Horn Switch (B):
Press this switch to blow the horn.
C
B
A
Head Light and Parking Light Switch (C):
This switch illuminates all lights (parking light, head light,
high beam, low beam) with the clockwise rotation.
Side Indicator Switch (A):
This switch is used for indicating the vehicle turn. Move turn
signal lever left to indicate left (L) hand turn or right (R) for
right hand turn. Indicator lights will flash according.
1
5
2
3
4
(1) Hazard Warning Light Switch
(2) Cruise ON-OFF Switch
(3) Combination Switch
(4) Ignition Switch
(5) PTO ON-OFF Switch
30-8
