INSTRUMENTS & CONTROLS
PTO Monitor Lamp
This lamp will turn ON, when PTO clutch engaged.
1
Trailer Turn Indicator
This indicates the working of left and right side
indicators lights of the trailer attachment.
It glows all the time when hazard switch is ON.
7-Pin socket is used for connection of trailer lights.
Engine RPM and Hour Meter
Needle of this meter indicates speed of engine in revolution
per minute and the hour meter indicates the number of
hours worked by the engine.
NOTE: Hour meter reading may defer from actual hour
(as per clock). This purely depends on engine RPM.
Safe operating
zone
30-6
