Summit TX25H - Checking Engine Oil Level; Replacement of Oil Filter & Engine Oil

Checking Engine Oil Level
Before checking the oil level be ensure that tractor is parked
on leveled ground. Stop the engine and wait for some time,
as all oil should return to oil sump.
Check the oil level by unscrewing dipstick (located at RHS of
the Engine). Top up the oil level if the level is below the
minimum level mark. Do not over fill than maximum level
mark. Oil level should be between maximum and minimum
marks .
Recommended grade & oil capacity of engine oil is listed at
the end of this chapter.
Dipstick marks
Changing Oil Filter:
Replacement of Oil Filter & Engine Oil
4. Apply clean engine oil to gasket on the new oil filter.
3. Take new oil filter and check it for proper seating of gasket.
1. Stop your tractor to the side of road on leveled surface and
drain the engine oil in an oil pan after removing the drain plug.
2. Remove the oil filter by rotating it in anti-clockwise direction
by hand or with the filter wrench.
5. Install oil filter. When the filter gasket contacts the mounting
surface of filter, tighten the new oil filter.
Refilling Engine Oil :
4. Ensure that oil level should be between the max. & min.
marks on the dipstick. If less, then pour the oil to bring it to
specified level.
2. Fill the engine oil with the specified engine oil to the
specified level to sump capacity from oil filler cap.
1. Re-install the drain plug and remove the oil filler cap .
6. Check the oil pan and other parts for oil leakage.
7. Start the engine, allow it to run idle and don't race it
immediately.
3. Insert into the oil level gauge guide, then pull out the gauge
again.
5. Install the oil filler cap after a refill.
˚
0˚C
10 20 30 40 50-10-20
-30
-40
0
-20-40
20
40 60 80 100
120
32˚F
SAE 30
SAE 0W - 40
SAE 5W - 30
SAE 10W - 30
SAE 10W - 40
SAE 15W - 40
Engine Oil Filter
Oil Filler Cap
