OPERATION
Under Hood Muffler
Under hood muffler fitted inside the hood for better
aesthetics, vision and better sound muffing capabilities.
Lift the hood slightly and it will automatically lift up to the
preset height with the assistance of gas spring.
Closing of Hood
Opening the Hood
Pull the knob (1) at front left side of the hood, till you hear a
click sound, to open the hood.
Gently lower the hood down, then press until lock is engaged.
1
Press pedal “B” to drive the tractor in reverse direction.
There are two speed control pedals provided to drive the
tractor in forward and reverse direction.
Press pedal “A” to drive the tractor in forward direction.
A
B
Do not shift from forward speed to backward speed
or vice versa suddenly in high range. Sudden
change may damage mechanism and cause risk of
injury to operator.
WARNING
Speed Control Pedals
40-4
