INSTRUMENTS & CONTROLS
Parking Brake Indicator
It glows when parking brake lever is in engaged
condition.
Battery Charge Indicator
This indicator indicates that either battery is being charged or not.
Refer the below given observations with respect to different
CONDITIONS
IGNITION SWITCH ENGINE INDICATOR
ON
ON
ON
ON
OFF
OFF
Start/Running
Start/Running
GLOW
OFF
OFF
GLOW
Battery Charging
System Functioning
OK
Charging system/battery is defective,
Get both thing checked from electrician
Battery being charged
Charging system is defective/battery
is draining out, get the charging system
checked from electrician.
Air Filter Clogging Indicator
This light will glow when the air filter is clogged. Clean the
air filter element immediately with air pressure
if this light is glowing.
Left Turn Indicator
It glows when the left side indicator is switched ON.
30-3
