Normal Operating Position-
For normal operation, including transport, always use the
ROPS in the upright position with a fastened seat belt for full
rollover protection.
Following procedure is folding the ROPS
Operating Foldable ROPS-
1. Remove R-pin (1) from pin(2) and then remove pin (2)
2. Turn the ROPS towards backward until rest on stopper.
3. Install the pin with the R-Pin on down position.
40-17
from ROPS frame.
1
2
