2 Sun StorageTek 2500 Series Array Hardware Installation Guide • March 2007
FIGURE 1-1 Sun StorageTek 2500 Series Array Product Overview
Front-Access Components of the Trays
Components that are accessed through the front of the Sun StorageTek 2540 Array,
the Sun StorageTek 2530 Array, and the Sun StorageTek 2500 Array are identical in
appearance. The disk drives in your controller tray might differ in appearance from
those shown in FIGURE 1-2. The variation does not affect the function of the disk
drives.
Expansion trays
Controller tray
Local
management host
Remote
management host
Host 1
Host 2
Host 3
Host 4
Redundant Fibre Channel
FC switch
FC switch
Ethernet out-of-band
Data hosts
Host 5
