Functional Details 57
E500 Series Universal Low-Power Inverter
2: Mode of keeping final value
The basic running way is the same as the mode 0. After the completion of the
single cycle, the inverter will not stop after completion of a single cycle and
continues running at the last speed for which the time is not set to zero. Other
process is the same as model 1.
3: Keeping setting value mode
The basic running way is the same as the mode 0. After the completion of the
single cycle, the inverter will not stop after completion of a single cycle and
continues running at the last speed for which the time is not set to zero. Other
process is the same as model 1.
4: Continuous cycling mode
The basic running way is the same as the mode 0. The inverter will start cycling
from the first speed after completion of one cycle.
The inverter runs in a cycle of 8 different speeds. That is to say, after completion
of running at the 8
th
speed, it will start running in a cycle from the first speed.
[F3.18]～[F3.21] Multi-speed frequency 1～4 running time
Note: the running time at different stage means the time from the end time
of previous stage to the end time of the current stage, including the accele-
ration time or deceleration time for running to the current stage frequency.
F3.18 Stage 1 running time Setting range: 0.0 ~ 6000 Sec
F3.19 Stage 2 running time Setting range: 0.0 ~ 6000 Sec
F3.20 Stage 3 running time Setting range: 0.0 ~ 6000 Sec
F3.21 Stage 4 running time Setting range: 0.0 ~ 6000 Sec
