56 Function Parameter Table
E500 Series Universal Low-Power Inverter
Setting of basic characteristics of multi-speed running(fratile decimal system
setting)
LED UNITS: Simple PLC action selection
0: Simple PLC void
1: Simple PLC effective
2: Simple PLC conditionally effective
When LED Units is selected to 1 (PLC effective), after the inverter has started,
at the frequency channel priority allowed status, the inverter will enter the
simple PLC running status.
When the LED Units is selected to 2 (PLC conditionally effective), when external
PLC input terminal is effective(PLC input terminal is selected by parameter
[F1.08]～[F1.11]), the inverter will run at the simple PLC mode; when the external
input terminal is void, the inverter will automatically enter the frequency setting
mode with lower priority.
LED Tens: Selection of simple PLC running mode
0: Single cycle mode
The inverter will firstly runs at the set frequency of the first-section speed, and
outputs frequency at each speed according to setting time. If the set running time
is 0 at certain section of speed, it will skip over this speed section. The inverter
will stop output after end of one cycle, and will not start the next cycle unless
the effective running command is input again.
1: Single cycle stop mode
The basic running way is the same as the mode 0, and the difference is that the
inverter firstly reduces the output frequency to 0 according to the specified
acceleration time after completion of running at certain speed, and then outputs
the next section of frequency.
F3.15 ~F3.16 Reserve
F3.17 Multi-speed running mode Setting range: 0000~0042H
