6 Commissioning
6.1 Inspection before Commissioning.
No. Check Item Result
1
All cables are intact, well-insulated, and appropriately
dimensioned.
□
2 All cables are connected correctly and firmly. □
3
The polarity of the power supply cable is correct. The
grounding cable is reliably grounded.
□
6.2 Commissioning Step
Item Description
1
Connect the commissioning PC to one of ETH1, ETH2, ETH5 ports of the logger
with a network cable.
• ETH1, default IP: 12.12.12.12, virtual IP: 15.15.15.15
• ETH2, default IP: 13.13.13.13, virtual IP: 16.16.16.16
• ETH5, default IP: 14.14.14.14, virtual IP: 17.17.17.17
2 Power on the Data Logger.
3
Observe whether the indicator RUN at the exterior of the Data Logger flickers
normally.
4
Access the default IP address of the connected port using Internet Explorer,
Safari, or Chrome.
5 Configure serial port parameters on the Web interface.
6
Add PV devices connected to the Data Logger to the Web interface by searching
for them or manually adding them.
7 Configure IP address.
8
Configure iSolarCloud address if inverter data needs to be uploaded to
iSolarCloud.
The default iSolarCloud server is "Chinese Server".
Users in mainland China select “Chinese Server”.
Users in Europe select “European Server”.
Users in Australia select “Australian Server”.
Users in other regions select “International Server”.
