8 Grid Dispatching Function User Manual
step 3 Set AI control parameters. For specific parameter description, refer to the following table.
table 8-3 Parameters description
Parameters Description
Control Method
• Open-Loop Control: Active dispatching command is sent to the
power output port of the inverter, thereby achieving active power
control.
•
Closed-Loop Control:
- When not using a Smart Energy Meter, at the start time,
the active power command is set as the target value.
Multiple adjustment algorithms are applied to calculate the
proportional value of active power compensation, which
is then sent to the power output port of the inverter. This
method is generally used for fast and accurate active power
regulation.
- When using a Smart Energy Meter, at the start time, the
active power command is set as the target value, and the
active power is collected by the meter as an input parameter.
A closed-loop control algorithm is then used to calculate the
proportional value of active power compensation, which is
then sent to the power output port of the inverter. This method
is generally used for anti-backflow or zero power feed-in.
Select Meter* Select a Smart Energy Meter for power regulation
Control Cycle
Time interval of delivering dispatching commands
Range: 5~60s
AI Port AI1~AI4 available
Instruction Type
kW: set active power value
%: set active power percentage
Min/Max
When Instruction Type is set to %, the lower and upper limit is
0.0%~100.0%.
When Instruction Type is set to kW, the lower and upper limit is 0.0
kW~999999 kW.
Step
The minimum difference value between two consecutive power
dispatching commands
The parameters noted with * refer to the parameters that need to be set only when Control
Method is set to Closed-Loop Control.
step 4 After finishing the configuration, click Save to apply the changes.
- - End
