33
No. Name No. Name
A
Copper bus
D
Disc spring washer
B
Cable lug
E Flat washer
C Bolt F Nut
• If aluminum wire is selected, a copper-aluminum adapter terminal is required, as
shown below:
No. Name No. Name
A
Copper bus
D
Disc spring washer
B
Copper-aluminum
adapter terminal
E Flat washer
C Bolt F Nut
System Manual 6 Electrical Installation
