About This Manual
1.1 Validity
This Installation Manual is valid for the following device types:
• SC1200UD
• SC1375UD
• SC1575UD
• SC1725UD
• SC2000UD
• SC2500UD
The Power Conversion System device is referred to as “PCS” hereinafter unless otherwise
specified.
1.2 Contents
This manual mainly contains the following content.
Content
Description
Safety
Instructions
Safety instructions for operation and maintenance of the PCS.
Product
Description
System composition, PCS function and operation mode.
Delivery Introduce the delivery and check after receiving the PCS.
Installation
guide
Introduce the mechanical installation, electrical installation, communica-
tion connection and installation check methods of the PCS, as well as
suggestions for installation space and cable connection.
Commission-
ing
The safety instructions of commissioning and commissioning processes
are introduced.
Start/Stop
Steps to start and stop the PCS internal devices during normal mainte-
nance or troubleshooting.
Use
Introduce the operation and use of human-machine interface (HMI) and
Web Server of the PCS.
Troubleshoot-
ing
Introduce the potential faults and troubleshooting methods of the PCS.
