23
[ Fig. 25 ]
14) Attaching and Removing the V-Belt(A Series)
A. Unfasten the fixing nuts ① and ②, and take off the belt cover ③.
B. Attach a handle ④ and lift it to the arrow direction.
C. Fix it by using a frame support bracket ⑤.
D. Take off the V-belt ⑥.
②
④
⑤
⑤
⑥
③
①
